Product Description
Suitable for use with M66 and M90 Steering Cables
Planetary Gear Design.
Particularly suitable where clearance is limited.
All stainless steel cable output ends as per ABYC safety standards.
Made exclusively in corrosion resistant materials.
Optional 90° or 20° installation.
Standard 3/4" tapered shaft.
Maximum steering wheel diameter: 406mm (16").
Stroke: 228mm (9").
Minimum steering cable bend radius 200mm (7.9").
Maximum operating load at the tiller end:3300N (340kg; 750lbs).
Should not be used on boats equipped with engines that exceed the max horsepower rating of the boat.
For boats faster than 50mph the twin cable steering system is recommended.
